Features
● NKW40Q Full automatic Baler Machine Specialized in recycling and compressing the loose materials like plastic films ,PET bottles, plastic pallets ,waste paper ,grass ,fiber ,used clothes ,cartons ,cardboards trims ,scrap,This Equipment Adope Photoelectric switch activates baler when charge box is full,
● NKW40Q Fully automatic baling machine,its suitable for Loose or small pieces of material to compress, after baling it is easy store and reduce the transportation cost.
● This automatic baler with Unique automatic strapping device,use steel wire to bundle the bales, speed quickly ,frame simple, motion steady. meanwhile ,the Failure rate is low and easy to clean maintenance.
● NKW40Q Full automatic baler Can choose transmission line materials and air-blower Feeding. Suitable to waste soft paper recycling companies, plastic, fabric , garbage disposal sites and so on.
● Adjustable bales length and bales quantity accumulating function make the operation of the machine more convenient
● Automatically detect and show the errors of the machine on screen Panel which improve the machine inspection efficiency
NKW40Q Automatic Baler machine Specification :
|
Item |
Name |
parameter |
|
mainframe parameter |
Bale size |
750mm（W）×750mm（H）×～1600mm(L) |
|
Material type |
Scrap Kraft paper, Carton, Cardboard ,Soft Film |
|
|
Material density |
200～300Kg/m3 |
|
|
Feed opening size |
1000mm×720mm |
|
|
Main motor power |
22KW×1 Set |
|
|
Main cylinder |
YG150/125-1600 |
|
|
Main cylinder force |
40T |
|
|
Max. system working force |
18MPa |
|
|
Output capacity |
About 5 -8tons /Hour |
|
|
Mainframe weight(T) |
About 8 tons |
|
|
Tie wire line |
4 line φ2.75～φ3.0mm3 iron wire |
|
|
Pressure time |
≤25S/ (go and back) |
|
|
Machine size |
6.7M*3.6M*2.3M |
|
|
Chain conveyor |
Size |
1200㎜（W）*10000㎜（L） |
|
Motor power |
4KW |
|
|
Control way |
Automatic / manual |
