NKW60Q fully automatic horizontal baler, applicable for recyclers handling large daily amount of soft waste such as cardboard/OCC ( popular as cardboard baler or OCC baler ) , paper, plastic film, natural fiber, textile waste, soft plastic package, newspapers maganizes etc
NKW60Q Horizontal Waste Paper Baler,Hydraulic Scrap Baling Press Introduction
Nowadays, industrial hydraulic baling press machines come in all shape and sizes, and they have all manner of characteristics depending on the type of materials which they bale. These waste compactors are generally made of steel with one or two hydraulic rams to compress the loaded material. That is why some call the baling press as hydraulic baling press, which is mainly used for compressing a volume of materials into certain shape for transportation and storage.Which is NKBALER has this funciton of works and they do proper for end users
Application Of Hydraulic Scrap Baling Press
Hydraulic baler can be used to compact various types of reusable resources and waste, such as paper, cotton, tyre, plastic, foil and cans, textile waste, natural and animal fiber, and so on. Particularly, it is fit to bale scrap, so it can be used as scrap baling press.
NKW60Q horizontal type baler machine Specification
|
Item |
Name |
parameter |
|
mainframe paramete |
Bale size |
750mm（W）×850mm（H） |
|
Material type |
Scrap Kraft paper, Carton, Cardboard ,Soft Film |
|
|
Material density |
300～400Kg/m3 |
|
|
Feed opening size |
1200mm×750mm |
|
|
Main motor power |
22KW |
|
|
Main cylinder |
YG180/125-1700 |
|
|
Shrink Cylinder |
YG180/125 |
|
|
Shrink way |
Three side shrink month |
|
|
Main cylinder force |
60T |
|
|
Max. system working force |
21MPa |
|
|
Output capacity |
About 1-3 tons /Hour |
|
|
Mainframe weight(T) |
About 10 tons |
|
|
Tie wire line |
4 line φ2.75～φ3.0mm3 iron wire |
|
|
Pressure time |
≤25S/ (go and back) |
|
|
Machine size |
6.7M*3.6M*2.3M |
|
|
Chain conveyor |
Size |
8000*700MM |
|
Motor power |
5.5KW |
|
|
Control way |
Automatic / manual |
