NKW160Q OCC Paper Baler Press Machine is a high -performance waste paper compressed packaging machine that is suitable for waste paper recycling and processing of various scale. The machine is made of advanced technology and high -quality materials, which has the characteristics of simple operation, high efficiency, and low energy consumption. It can compress the waste paper into a compact mass, facilitate transportation and storage, reduce the space occupied by waste paper, and improve the recycling rate of waste paper. In addition, the machine also has the advantages of high degree of automation, low noise, and convenient maintenance. It is an ideal equipment for the waste paper recycling industry.
NKW160Q OCC Paper Bale Press Machine is an efficient, economical waste paper compressed packaging NKW160Q OCC PAPER BALER PRESS MACHINE is an efficient, economical waste paper compressed packaging machine. Its Bale Size is 1100mm (W) × 1100mm (H) × ~ 1600mm (L). It has a large storage space and can effectively reduce the space occupied by waste paper. In addition, the machine also has the characteristics of high efficiency and low energy consumption, which can complete a large amount of waste paper compression work in a short time, which greatly improves the recycling rate of waste paper. The machine is made of advanced technology and high -quality materials, which has the characteristics of simple operation, high efficiency, and low energy consumption. Its Mainframe Weight is about 25 Tons, equipped with a powerful power of 45kW+15kW, which can meet the needs of long -term continuous operations. At the same time, the machine also has a good degree of automation, making the operation easier and more convenient. In general,NKW160Q OCC Paper Baler Press Machine is a superior performance, economical and practical waste paper compressed packaging machine, and is an ideal choice for the waste paper recycling industry.
| Item | Name | parameter |
| mainframe parameter | Bale size | 1100mm（W）×1100mm（H）×～1600mm(L) |
|
| Material type | Scrap Kraft paper, Newspaper, Cardboard ,Soft Film， |
|
| Material density | 600～700Kg/m3(Mositure12-18%） |
|
| Feed opening size | 2400mm×1100mm |
|
| Main motor power | 45KW+15kw |
|
| Main cylinder | YG280/210-2900 |
|
| Capacity | 12-15 ton /hour |
|
| Main cylinder force | 160T |
|
| Max. system working force | 30.5MPa |
|
| Mainframe weight(T) | About 25 tons |
|
| Oil tank | 2m3 |
|
| Mainframe size | About 11×4.3×5.8M（L×W×H） |
|
| Tie wire line | 4 line φ3.0～φ3.2mm3 iron wire |
|
| Pressure time | ≤30S/ (go and back for empty load) |
| Chain conveyor technology | Model | NK-III |
|
| Conveyor weight | About 7 tons |
|
| Conveyor size | 2000*14000MM |
|
| Conveyor motor | 7.5KW |
| Cool tower | Cool tower motor | 0.75KW（water Pump）+0.25（Fan） |
